Fraunhofer Institute for Building Physics IBP
Moisture distribution, NMR
Hygrothermics
| Measurement | Moisture distribution, moisture profile, penetration depth |
| Measurement object | Building materials, drilling core, insulation materials, etc. |
Technical data
| Sample size | Prisms with a max. width of 50 mm Drilling cores with a max. diameter of 50 mm |
| Apparatus | NMR spectroscopy |
Special features
| Accredited by DAkkS D-PL-11140-11-02 |
The laboratory has a flexible accreditation according to DIN EN ISO/IEC 17025 Test laboratory moisture, mortar, radiation, emmissions |
| Test reports can be issued |
More information
- The contribution of weakly bounded protons in a material can be determined with this method. Therefore the moisture distribution at a certain time in materials or a combination of materials can be determined. Also the changes of the profiles, e.g., during a water uptake experiment or during a drying experiment, can be determined.
- The procedure can be used to determine the penetration depth of hydrophobic agents, impregnations or stone strengthening agents.
